T1N 2001-2006 Sprinter Van Aftermarket Projection Headlights for Upgrade Replacements


Tax Included Pricing

In Stock in USA | Ships within a couple days.



SKU: T1N-Projection-Headlights Category: Tags: ,


Dodge Sprinter without Factory Fog Lights for 2001-2006 Sprinter Van


MERCEDES SPRINTER W903 W905 2000 - 2006


The kit includes complete lamps with lenses, xenon filaments and xenon converters.

The bulbs of the parking lights / high lights / indicator, etc.,
and the adjustment motors are left to transfer from the old lamps.

THE OFFER APPLIES TO LAMPS WITH A CHROME CENTER, WITHOUT RINGS AS DAYTIME / PARKING LIGHT As standard, we send lamps with 4300k filaments. If you want to receive lamps with filaments of a different color - no extra charge (6000k, 8000k, 10000k) - please let us know. Lamps fit cars with original halogen lamps. In the case of cars where xenon lamps were originally used, it may be necessary to change the plug / modify the electrical system. Lamps should be adjusted after installation in a diagnostic station. THE HEADLAMPS HAVE A EUROPEAN LIGHT CUT-OFF LINE. The lenses have a bixenon option. On the short lights the lens with the diaphragm (with the cut-off line) lights up, on the long lights the diaphragm is exposed (electromagnet) and the xenon shines with the whole lens. Additionally, when the high beam lights are turned on, the auxiliary halogen bulb is turned on. It is a real bixenon, the same as in factory car installations. The xenon converter is placed inside or outside the lamp, depending on the structure of the reflector. The converters used are digital! This ensures a longer service life and better light quality than in the case of cheap analog converters. The offer applies to a set of new lamps (without sending back the old ones) The headlamps have E (E4, E13 or other) and HC / HR (halogen approvals) approval. The headlamps are not xenon approved.

Click Here: How to Install Headlights on your T1N 2001-2006 Sprinter Van

114-01179L, 5103598AA, CH2502172, B01NAAOYIX, 11716324, 000708374, 05124526AA, 05103598AA

114-01178R, 5103599AA, CH2503172, B01MZWT0NK, 11716397, 000667707, 05124528AA, 05103599AA

Confirmed T1N Sprinter Fitment:
2001 Freightliner Sprinter Van
2002 Freightliner Sprinter Van
2003 Freightliner Sprinter Van
2004 Freightliner Sprinter Van
2005 Freightliner Sprinter Van
2006 Freightliner Sprinter Van
2003 Dodge Sprinter Van
2004 Dodge Sprinter Van
2005 Dodge Sprinter Van
2006 Dodge Sprinter Van

Additional information

Weight 10 lbs
Dimensions 24 × 18 × 12 in
Headlight Side

Passenger Side Headlight, Driver Side Headlight, Both Driver+Passenger Set
